DDR3 ECC U-DIMM

Server
1066 / 1333 / 1600 / 1866
  • Single bit error correction and detection available
  • Designed for optimized performance and reliability
  • Uses original IC to meet strict industrial standards
  • JEDEC standard VDDQ=1.5V (1.425V~1.575V) & 1.35V (1.283V~1.418V)
  • Operating temperature : 0°C ~ 85°C
  • 30μ” gold finger
  • Lead-free (RoHS compliant)
  • CE/FCC certification
  • Temperature Sensor (Optional)

Industrial DDR3 Memory Module

TEAMGROUP announces its industrial DDR3 memory module product with leading technology. They are available in 1.5V standard operating voltage or 1.35V low operating voltage, and also supports ECC function to detect and correct data errors.
They have been through strictly controlled processes and manufactured under rigorous process. Every memory module has been through strict testing procedures and burn-in verification and is 100% tested pass. They have high compatibility, stability and excellent performance, vastly reducing product compatibility issues. They have all passed strict electrical interference and noise tests, ensuring that no electrical interference will be generated for every memory module to cause problems, fulfilling TEAMGROUP Industrial product's promise to meet the demand for high-quality. Not only strict and rigorous production processes are used to ensure the quality of every memory module, TEAMGROUP's all series memory module products have lifetime warranties so that you can use them with ease and also enjoy the best qualities.

proIns_img02
Frequency
1066 / 1333 / 1600 / 1866
Capacity
2GB / 4GB / 8GB
Pin Count
240pin
Width
72Bits
Voltage
1.5V / 1.35V
PCB Height
1.18 Inches
Standard Operating Temperature
0°C (+32°F) ~ +85°C (+185°F) (Tc +95°C)
Extended Operating Temperature
-40°C (-40°F) ~ +85°C (+185°F) (Tc +95°C)
Shock
Operation: 50G / 11ms (compliant with MIL-STD-202G Test condition A)
/Non-operation: 1,500G / 0.5ms (compliant with MIL-STD-883K Test condition B)
Vibration
Operation: 7.69 Grms, 20~2,000 Hz / random (compliant with MIL-STD-810G General)
Non-operation: 4.02 Grms, 15 ~ 2,000 Hz / sine (compliant with MIL-STD-810G General)
Anti-Sulfuration
-
Gold Finger
30μ”
Value-Added Service
Conformal Coating
Warranty
Limited Lifetime
NOTES:
We reserve the right to modify product specifications without prior notice.



Frequency Capacity COMPONENT
COMPOSITION
RANK Team P/N
1333 2GB 256Mx8 1RX8 TE2GKLEW3NS
1333 4GB 512Mx8 1RX8 TE4GKLEW3HH
1333 8GB 512Mx8 2RX8 TE8GKLEW3HH
1600 2GB 256Mx8 1RX8 TE2GKLEW6NS
1600 4GB 512Mx8 1RX8 TE4GKLEW6HH
1600 8GB 512Mx8 2RX8 TE8GKLEW6HH
1866 2GB 256Mx8 1RX8 TE2GKLEW8NS
1866 4GB 512Mx8 1RX8 TE4GKLEW8HH
1866 8GB 512Mx8 2RX8 TE8GKLEW8HH
